| Detail Information
| Model Number | HTP56S252P1R | Power: | 18/24/35/42W |
| Material: | Anti UV PC, Fully Resin Filled | Color: | RGB/RGBW/CW/WW/R/G/B |
| Size: | 177*25mm | Input Voltage(V): | AC/DC 12V/24V |
| Control Method: | Remote/Switch Control/Tuya/Wifi | IP Rating: | IP68 |
| Warranty: | 2-Year | Working Temperature(℃): | (-20C°) -( 40C°) |
| Service: | OEM/ODM |
| Feature
Ful resin filled, 100% IP68 waterproof
Portable small design in 9.4 ” diameter
Works for concrete pool
Nicheless—directly install on the wall, easy to install
| Description
The lamp body is made of PC material, which is tight and durable, and has good corrosion resistance and crack resistance.The light-transmitting cover is made of transparent material withextremely high strength, which has good light transmission,The use of high brightness LED lamp beads, LED lamp beads, high brightness, low consumption can produce uniform light, soft light, long life, energy saving and environmental protection
DC12V low voltage safety no electric shock 12V low voltage power supply, human contact will not have the risk of electric shock, rest assured。
Thickened PC material, resin seal design, good waterproof performance, with good corrosion resistance and pressure resistance.
Super waterproof design, resin filling process waterproof, silicone sealing waterproof, waterproof connector triple protection, safer use.
High brightness import, chip high brightness import chip, high brightness, low energy consumption, low light decay, uniform light, soft light, energy saving and environmental protection.
The bottom of wall-mounted installation is made of PBT, screw seal waterproof design, wall-mounted installation is convenient and fast
Suitable for a variety of scenarios, indoor swimming pool, outdoor swimming pool, fountain lighting and other outdoor lighting.
| INSTALLATION
1. Remove the support from the lamp Step
2. Fasten the support to the wall of the pool with screws Step
3. Use screws to secure the lamp to the support Step
4. Connect the cable to the 12V or 24V converter (The lamp cannot directly connect to the 110V or 220V power supply). A waterproof transformer or junction box is strongly recommended
